Recoil - #3-48 UNC, 2D, Stainless Steel Screw Locking Insert - 7-1/4 Free Coils, 0.198 Inch Overall Length, 0.128 to 5/36 Inch Outside Diameter, with Tang, Bright Finish
Item #: 91907386
Brand: Recoil
Model #: 13534
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | #3-48 |
Overall Insert Length (Decimal Inch) | 0.1980 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 2D |
Length to Diameter Ratio | 2D |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.1280 |
Maximum Outside Diameter (Decimal Inch) | 0.1390 |
Finish/Coating | Bright |
Number of Free Coils | 7-1/4 |
Maximum Locking Torque (oz-in) | 32 |
Mininum Break Away Torque (oz-in) | 7.00 |
Thread Standard | UNC |
