![Recoil - #3-48 UNC, 1-1/2D, Stainless Steel Screw Locking Insert - 5 Free Coils, 0.148 Inch Overall Length, 0.128 to 5/36 Inch Outside Diameter, with Tang, Bright Finish - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/9190677-11_03242540-ee05-4673-ba82-004ec49d8505_1024x1024.jpg?v=1586462779)
Recoil - #3-48 UNC, 1-1/2D, Stainless Steel Screw Locking Insert - 5 Free Coils, 0.148 Inch Overall Length, 0.128 to 5/36 Inch Outside Diameter, with Tang, Bright Finish
Item #: 91907360
Brand: Recoil
Model #: 13533
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | #3-48 |
Overall Insert Length (Decimal Inch) | 0.1480 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Length to Diameter Ratio | 1-1/2D |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.1280 |
Maximum Outside Diameter (Decimal Inch) | 0.1390 |
Finish/Coating | Bright |
Number of Free Coils | 5 |
Maximum Locking Torque (oz-in) | 32 |
Mininum Break Away Torque (oz-in) | 7.00 |
Thread Standard | UNC |
