Recoil - #3-48 UNC, 1D, Stainless Steel Screw Locking Insert - 2-7/8 Free Coils, 0.099 Inch Overall Length, 0.128 to 5/36 Inch Outside Diameter, with Tang, Bright Finish
Item #: 91907345
Brand: Recoil
Model #: 13532
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | #3-48 |
| Overall Insert Length (Decimal Inch) | 0.0990 |
| Tang | Yes |
| Tang | Tangless |
| Length to Diameter Ratio | 1D |
| Length to Diameter Ratio | 1D |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.1280 |
| Maximum Outside Diameter (Decimal Inch) | 0.1390 |
| Finish/Coating | Bright |
| Number of Free Coils | 2-7/8 |
| Maximum Locking Torque (oz-in) | 32 |
| Mininum Break Away Torque (oz-in) | 7.00 |
| Thread Standard | UNC |
