Recoil - 1/2-13 UNC, 2D, Stainless Steel Screw Locking Insert - 11 Free Coils, 1 Inch Overall Length, 0.597 to 0.622 Inch Outside Diameter, with Tang, Bright Finish - Exact Industrial Supply

Recoil - 1/2-13 UNC, 2D, Stainless Steel Screw Locking Insert - 11 Free Coils, 1 Inch Overall Length, 0.597 to 0.622 Inch Outside Diameter, with Tang, Bright Finish


Item #: 91907147
Brand: Recoil
Model #: 13084
Exact Tooling IR#: 04

Product Specifications
Thread Size 1/2-13
Overall Insert Length (Decimal Inch) 1.0000
Tang Yes
Tang Tangless
Length to Diameter Ratio 2D
Length to Diameter Ratio 2D
Material Stainless Steel
Minimum Outside Diameter (Decimal Inch) 0.5970
Maximum Outside Diameter (Decimal Inch) 0.6220
Finish/Coating Bright
Number of Free Coils 11
Maximum Locking Torque (In/Lb) 150
Minimum Break Away Torque (In/Lb) 24.00
Thread Standard UNC
$3.53

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It
