Recoil - 3/8-16 UNC, 3D, Stainless Steel Screw Locking Insert - 15-3/4 Free Coils, 1-1/8 Inch Overall Length, 0.452 to 0.472 Inch Outside Diameter, with Tang, Bright Finish
Item #: 91907030
Brand: Recoil
Model #: 13066
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | 3/8-16 |
| Overall Insert Length (Decimal Inch) | 1.1250 |
| Tang | Yes |
| Tang | Tangless |
| Length to Diameter Ratio | 3D |
| Length to Diameter Ratio | 3D |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.4520 |
| Maximum Outside Diameter (Decimal Inch) | 0.4720 |
| Finish/Coating | Bright |
| Number of Free Coils | 15-3/4 |
| Maximum Locking Torque (In/Lb) | 80 |
| Minimum Break Away Torque (In/Lb) | 12.00 |
| Thread Standard | UNC |
