![Recoil - 100 Inserts, 5/16-18 UNC, 2-1/2D, Stainless Steel Screw Locking Insert - 11-7/8 Free Coils, 25/32 Inch Overall Length, 0.38 to 0.4 Inch Outside Diameter, with Tang, Dry Film Lubricant - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/9190677-11_2d85bcc5-7565-4c13-8aa0-a7649eb15733_1024x1024.jpg?v=1586462287)
Recoil - 100 Inserts, 5/16-18 UNC, 2-1/2D, Stainless Steel Screw Locking Insert - 11-7/8 Free Coils, 25/32 Inch Overall Length, 0.38 to 0.4 Inch Outside Diameter, with Tang, Dry Film Lubricant
Item #: 91906925
Brand: Recoil
Model #: 13055D
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 5/16-18 |
Overall Insert Length (Decimal Inch) | 0.7810 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 2-1/2D |
Length to Diameter Ratio | 2-1/2D |
Number of Inserts | 100 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.3800 |
Maximum Outside Diameter (Decimal Inch) | 0.4000 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 11-7/8 |
Maximum Locking Torque (In/Lb) | 60 |
Minimum Break Away Torque (In/Lb) | 7.50 |
Thread Standard | UNC |
