Recoil - 100 Inserts, 1/4-20 Metric Fine, 3D, Stainless Steel Screw Locking Insert - 12-3/4 Free Coils, 3/4 Inch Overall Length, 0.31 to 0.33 Inch Outside Diameter, with Tang, Dry Film Lubricant
Item #: 91906842
Brand: Recoil
Model #: 13046D
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 1/4-20 |
Overall Insert Length (Decimal Inch) | 0.7500 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 3D |
Length to Diameter Ratio | 3D |
Number of Inserts | 100 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.3100 |
Maximum Outside Diameter (Decimal Inch) | 0.3300 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 12-3/4 |
Maximum Locking Torque (In/Lb) | 30 |
Minimum Break Away Torque (In/Lb) | 4.50 |
Thread Standard | Metric Fine |
