Iscar - 20mm Cut Diam, 17mm Max Depth of Cut, 48.8mm OAL, Indexable Ball Nose End Mill - 35mm Head Length, T12 Modular Connection, BCM-MM Toolholder, BCR D200 Insert
Item #: 91108555
Brand: Iscar
Model #: 3104290
Exact Tooling IR#: 04
Features and Benefits
Modular connections allow for single end mill to accept various shank diameters without changing machine toolholding set-ups.
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 20.00 |
| Maximum Depth of Cut (mm) | 17.00 |
| Shank Type | Modular Connection |
| Modular Connection Thread Size | T12 |
| Number of Ball Nose Inserts Used on Toolholder | 2 |
| Insert Style | BCR D200 |
| Toolholder Style | BCM-MM |
| Series | DropMill; Multimaster |
| Overall Length (mm) | 48.80 |
| Insert Holding Method | Screw |
| Through Coolant | NonThrough Coolant |
| Number of Flutes | 2 |
| Head Length (mm) | 35.00 |
| Neck Diameter (Decimal Inch) | 0.7280 |
