TPGN160304 TT8125 Carbide Turning Insert 1/8″ Thick, 60° Triangle
Item #: 87307294
Brand: Ingersoll Cutting Tools
Model #: 5520202
Product Specifications
Insert Style | TPGN |
Insert Shape Code | T |
Insert Size Code | 321 |
Insert Shape | Triangle |
Clearance Code | P |
Tolerance Code | G |
Insert Material | Solid Carbide |
Manufacturer Grade | TT8125 |
Maximum Depth of Cut (Decimal Inch) | 0.1970 |
Inscribed Circle (Inch) | 3/8 |
Inscribed Circle (Decimal Inch) | 0.3750 |
Insert Holding Method | Clamp |
Width (Inch) | 1 |
Insert Hand | Neutral |
Insert Thickness (Inch) | 1/8 |
Insert Thickness (Decimal Inch) | 0.1250 |
Corner Radius (Decimal Inch) | 0.0160 |
Included Angle | 60.0 |
Relief Angle | 11 |
Series | TPGN |
Coating Process | CVD |
Rake | Positive |
Wiper Edge | No |
Insert Length (Decimal Inch) | 0.6500 |
Number Of Cutting Edges | 3 |
Primary Workpiece Material | Steel |
Primary Workpiece Material Code | P |
Ansi Code | TPG321TT8125 |
Iso Code | TPGN160304 TT8125 |
Chip Breaker | N |
Width (Decimal Inch - 4 Decimals) | 1.0000 |
Coating/Finish | TiCN; TiN; Al2O3 |
