Value Collection - 1/2-13 UNC, 0.31" Cutting Diam, 5 Flute, Solid Carbide Helical Flute Thread Mill - Internal Thread, 0.7693" LOC, 2.48" OAL, 5/16" Shank Diam
Item #: 86380003
Brand: Value Collection
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Bright provides a smooth, polished finish on the tool. It increases chip flow in softer materials such as aluminum, wood and plastic.
| Product Specifications | |
|---|---|
| Threads Per Inch | 13 |
| Material | Solid Carbide |
| Thread Size (Inch) | 1/2-13 |
| Thread Type | Internal |
| Shank Diameter (Decimal Inch) | 0.3120 |
| Number of Flutes | 5 |
| Cutting Diameter (Decimal Inch) | 0.3100 |
| Length of Cut (Decimal Inch) | 0.7693 |
| Finish/Coating | Bright |
| Through Coolant | NonThrough Coolant |
| Minimum Nominal Diameter | 1/2 |
| Minimum Nominal Diameter (Decimal Inch) | 0.5000 |
| Overall Length (Decimal Inch) | 2.4800 |
| Thread Standard | UNC |
| Flute Direction | Right Hand |
| Material Grade | K27C |
