![Heli-Coil - Single Insert, M6x1 Metric Coarse, 2-1/2D, Stainless Steel Screw Locking Insert - 12-1/8 Free Coils, 15mm Overall Length, 7.4 to 7.95mm Outside Diameter, with Tang, Bright Finish - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/8576097-23_1024x1024.jpg?v=1586463080)
Heli-Coil - Single Insert, M6x1 Metric Coarse, 2-1/2D, Stainless Steel Screw Locking Insert - 12-1/8 Free Coils, 15mm Overall Length, 7.4 to 7.95mm Outside Diameter, with Tang, Bright Finish
Item #: 85760973
Brand: Heli-Coil
Model #: A4184-6CN150
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | M6x1.00 |
Overall Insert Length (mm) | 15.00 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 2-1/2D |
Length to Diameter Ratio | 2-1/2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (mm) | 7.40 |
Maximum Outside Diameter (mm) | 7.95 |
Finish/Coating | Bright |
Number of Free Coils | 12-1/8 |
Maximum Locking Torque (N/m) | 3.00 |
Minimum Break Away Torque (N/m) | 0.0030 |
Thread Standard | Metric Coarse |
