Heli-Coil - Single Insert, M2x0.4 Metric Coarse, 1-1/2D, Stainless Steel Screw Locking Insert - 5-1/2 Free Coils, 3mm Overall Length, 2.5 to 2.7mm Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade
Item #: 81774457
Brand: Heli-Coil
Model #: A4184-2CNW030
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M2x0.40 |
| Overall Insert Length (mm) | 3.00 |
| Tang | Yes |
| Tang | Tangless |
| Length to Diameter Ratio | 1-1/2D |
| Length to Diameter Ratio | 1-1/2D |
| Number of Inserts | 1 |
| Material | Stainless Steel |
| Minimum Outside Diameter (mm) | 2.50 |
| Maximum Outside Diameter (mm) | 2.70 |
| Finish/Coating | Dry Film Lubricant |
| Number of Free Coils | 5-1/2 |
| Maximum Locking Torque (N/m) | 0.12 |
| Minimum Break Away Torque (N/m) | 0.0030 |
| Thread Standard | Metric Coarse |
| Material Grade | 304 |
