Die Drill Bit: 0.7656″ Dia, 125 °, Solid Carbide Bright Finish, 7-7/8″ Flute, 9-7/8″ OAL, Series 170
Item #: 81220493
Brand: CJT
Model #: 17007656
Product Specifications
| Drill Bit Type | Straight-Flute |
| Drill Bit Size (mm) | 19.45 |
| Tool Material | Carbide |
| Coating/Finish | Bright |
| Flute Length (Inch) | 7-7/8 |
| Flute Length (Decimal Inch) | 7.8750 |
| Drill Point Angle | 125 |
| Overall Length (Inch) | 9-7/8 |
| Shank Diameter (Decimal Inch) | 0.7656 |
| Coolant Through | Yes |
| Drill Bit Size (Decimal Inch) | 0.7656 |
| Overall Length (Decimal Inch) | 9.8750 |
| Series | 170 |
| Number Of Flutes | 2 |
| Point Type | Faceted |
| Cutting Direction | Right Hand |
| Web Thinning | Web-Thinned |
| Coolant-Hole Shape | Round |
| Drill Bit Diameter Tolerance | +0.000 to -0.025 mm; +0.0000 to -0.0010 in |
| Primary Workpiece Material | Cast Aluminum; Ductile Iron; Cast Iron; Tool Steel; Abrasive Materials |
| Secondary Workpiece Material | Cast Aluminum; Ductile Iron; Cast Iron; Tool Steel; Abrasive Materials |
| Maximum Drilling Depth (Decimal Inch) | 6.3000 |
| Shank Diameter (Decimal Inch) | 49/64 |
