CJT - 23/32" 135° Spiral Flute Carbide-Tipped Screw Machine Drill Bit - TiN Finish, Right Hand Cut, 3-15/16" Flute Length, 6-11/32" OAL, Helical Point, Straight Shank, Through Coolant
Item #: 81211468
Brand: CJT
Model #: 29607188
Exact Tooling IR#: 04
Features and Benefits
Carbide tips cut faster than high speed steel. It is commonly used on ferrous and nonferrous metals including cast iron.
Titanium Nitride (TiN) is a multi-purpose coating which increases chip flow in softer materials. The heat and hardness resistance allows the tool to run at higher speeds than uncoated tools.
Spiral flutes are constructed of a higher flute angle to remove chips easier.
| Product Specifications | |
|---|---|
| Drill Bit Size (Decimal Inch) | 0.7188 |
| Drill Bit Size (Inch) | 23/32 |
| Drill Point Angle | 135 |
| Drill Bit Material | Carbide-Tipped |
| Drill Bit Finish/Coating | TiN |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Shank Type | Straight |
| Flute Length (Inch) | 3-15/16 |
| Overall Length (Inch) | 6-11/32 |
| Point Type | Helical |
| Shank Diameter (Inch) | 45/64 |
| Maximum Drilling Depth (Decimal Inch) | 2.9000 |
| Spiral Type | Slow Spiral |
| Number of Flutes | 2 |
| Drill Bit Diameter Tolerance (mm) | +0.000 to -0.025 |
| Drill Bit Diameter Tolerance (Decimal Inch) | +0.0000 to -0.0010 |
| Series/List | 296 |
