Rotor Clip - 25.2mm Nominal, 1.2mm Thick, Phosphate Finish, Steel Snap Internal Retaining Ring - 1.3mm Groove Width, 0.6mm Groove Depth, 25.2mm Groove Diam, Grade 1060-1090
Item #: 81096158
Brand: Rotor Clip
Model #: DHO-24SG
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Snap |
| Material | Steel |
| System of Measurement | Metric |
| Bore Diameter (mm) | 24.00 |
| Nominal Size (mm) | 25.20 |
| Groove Diameter (mm) | 25.20 |
| Groove Width (mm) | 1.30 |
| Inside Diameter (mm) | 2.00 |
| Free Outside Diameter (mm) | 25.90 |
| Military Specification | Does Not Meet Military Specifications |
| Ring Thickness (mm) | 1.20 |
| Material Grade | 1060-1090 |
| Finish/Coating | Phosphate |
| Groove Depth (mm) | 0.60 |
| Groove Diameter Tolerance (mm) | -0.210 to 0.210 |
| Free Outside Diameter Tolerance (Decimal Inch) | -0.210 to 0.420 |
| Ring Thickness Tolerance (Decimal Inch) | 0.0020 |
| Thrust Load (Lb.) | 1730.960 (Groove Safety Factor); 3124.720 (Ring Safety Factor) |
| Hardness | Rockwell C 47-54 |
| Fastener Standard | SAE 1060-1090; UNS G10600-G10900 |
