Enerpac - 50 Ton, 2.38" Stroke, 22.85 Cu In Oil Capacity, Portable Hydraulic Low Profile Cylinder - 9.62 Sq In Effective Area, 4.81" Lowered Ht., 7.19" Max Ht., 3.5" Cyl Bore Diam, 2.75" Plunger Rod Diam, 10,000 Max psi
Item #: 80013568
Brand: Enerpac
Model #: RCS502
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Low Profile |
| Load Capacity (Ton) | 50 |
| Piston Stroke (Decimal Inch) | 2.38 |
| Cylinder Bore Diameter (Decimal Inch) | 3.50 |
| Lowered Height | 4.81 |
| Oil Capacity | 22.85 |
| Effective Area | 9.62 |
| Maximum Height (Decimal Inch) | 7.19 |
| Outside Diameter (Inch) | 4-7/8 |
| Plunger Diameter | 2.75 |
| Base To Inlet Port (Inch) | 15/16 |
| Plunger Internal Thread Size | M5 x 0.8 |
| Plunger Internal Thread Length | 0.32 |
| Base Mounting Holes Bolt Circle (Inch) | 1-9/16 |
| Maximum Pressure (psi) | 10000 |
