Mitutoyo - 8" Max Measuring Range, 0.0004" Resolution, 8" Scale Length, Glass DRO Linear Scale - 5+5L0/1,000 µm Accuracy, IP53, 9.84' Cable Length, 0 to 45°C, Series AT103
Item #: 79530523
Brand: Mitutoyo
Model #: 539-113-30
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Scale Type | Glass |
Maximum Measuring Range (mm) | 200.00; 220.00 |
Maximum Measuring Range (Inch) | 8 |
Maximum Measuring Range (Decimal Inch) | 8.6600 |
Resolution (Decimal Inch) | 0.000400 |
Scale Length (mm) | 368.00 |
Scale Length (Inch) | 8 |
Scale Length (Decimal Inch) | 14.4900 |
Accuracy (micrometer) | 5+5L0/1000 |
Accuracy (Decimal Inch) | 0.000400 |
Series | AT103 |
IP Rating | IP53 |
Cable Length (Decimal Inch) | 118.1100 |
Cable Length (Feet) | 9.84 |
Cable Length (Meters) | 3.00 |
Operating Temperature Range (C) | 0 to 45 |
Storage Temperature Range (C) | -20 to 70 |
