Brand: Ingersoll Cutting Tools / Part #: 2914016
Item #: 98631104
Brand: Ingersoll Cutting Tools
Model #: 2914016
Product Specifications
| Connection Type | Shell Mount |
| Cutting Width (Inch) | 1/2 |
| Maximum Depth of Cut (Decimal Inch) | 1.0100 |
| Hole Diameter (Inch) | 1-1/2 |
| Cutter Diameter (Inch) | 6 |
| Shank Diameter (Decimal Inch) | 3.8000 |
| Shank Length (Decimal Inch) | 1.5000 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Number Of Cutter Inserts | 14 |
| Compatible Insert Style | IHX |
| Compatible Insert Size Code | 415 |
| Staggered Tooth | Yes |
| Tooth Type | Staggered Tooth |
| Rake | Negative |
| Tool Material | Steel |
| Series | 3VJ4V |
| Toolholder Style | 3VJ4V |
| Hub Diameter (mm) | 96.520 |
| Keyway Width (Decimal Inch) | 0.6300 |
| Tool Application | Slotting |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| Maximum Cutting Width (Decimal Inch) | 0.5000 |
| Maximum Body Diameter (Decimal Inch) | 6.0000 |
| Cutter Body Width (Decimal Inch) | 0.5000 |
| Weldon Flat | No |
| Manufacturers Catalog Number | 3VJ4V-0605058R01 |
| Overall Length (Inch) | 2 |
| Number Of Teeth | 14 |
| Coolant Through | No |
| Complete Insert Compatibility | INX415.. |
| Coating/Finish | Coated |
