Associated Spring Raymond - M10x1.5 Mt Hole, 3.15" Rod Diam, 4.72" Diam, 25mm Max Stroke, Nitrogen Gas Spring Cylinder - 6.1" OAL, 38,200 Lb Full Stroke Spring Force, 2,175 psi Initial Charge
Item #: 75003939
Brand: Associated Spring Raymond
Model #: CU 11800-025
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Diameter (Decimal Inch) | 4.7200 |
| Maximum Stroke (Decimal Inch) | 0.984 |
| Maximum Stroke (mm) | 25.00 |
| Spring Force Full Stroke | 38200 |
| Spring Force Initial | 26500.0 |
| Overall Length (Decimal Inch) | 6.1000 |
| Initial Charge Pressure | 2175 |
| Mounting Hole Thread Size | M10x1.5 |
| Rod Diameter (Decimal Inch) | 3.150 |
