Brand: Ingersoll Cutting Tools / Part #: 2927397
Item #: 60634219
Brand: Ingersoll Cutting Tools
Model #: 2927397
Product Specifications
| Minimum Cutting Diameter (Decimal Inch) | 2.5000 |
| Minimum Cutting Diameter (Inch) | 2-1/2 |
| Maximum Cutting Diameter (Decimal Inch) | 2.5000 |
| Maximum Cutting Diameter (Inch) | 2-1/2 |
| Maximum Depth of Cut (mm) | 108.25 |
| Maximum Depth of Cut (Decimal Inch) | 4.2620 |
| Cutter Style | 2XJ3J |
| Shank Type | Taper |
| Maximum Ramping Angle | 0 |
| Insert Holding Method | Screw |
| Shank Taper Size | CV50 |
| Overall Length (mm) | 254.0000 |
| Overall Length (Decimal Inch) | 10.0000 |
| Tool Material | Steel |
| Series | 2XJ3J |
| Flute Type | Spiral |
| Lead Angle | 90 |
| Shank Length (Inch) | 4 |
| Shank Length (Decimal Inch) | 4.0000 |
| Head Length (Decimal Inch) | 4.6300 |
| Tool Application | Facing; Shouldering |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| End Mill Type | Shoulder Square End Mill |
| Rake | Negative |
| Complete Insert Compatibility | IPM426..; IPM324.. |
| Insert Compatibility | IPM426..; IPM324.. |
| Hand of Holder | Right Hand |
| Multi-Use Tool | Yes |
| Manufacturers Catalog Number | 2XJ3J-2506048R01 |
| Usable Length (mm) | 117.600 |
| Number Of Flutes | 5 |
| Usable Length (Decimal Inch) | 4.6300 |
| Number Of Cutter Inserts | 45 |
| Coolant Through | Yes |
