![Heli-Coil - Single Insert, 1/4-20 UNC, 1-1/2D, Titanium Screw Locking Insert - 5-3/4 Free Coils, 3/8 Inch Overall Length, 0.31 to 0.33 Inch Outside Diameter, with Tang, Bright Finish - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/7054781-11_1024x1024.jpg?v=1586838474)
Heli-Coil - Single Insert, 1/4-20 UNC, 1-1/2D, Titanium Screw Locking Insert - 5-3/4 Free Coils, 3/8 Inch Overall Length, 0.31 to 0.33 Inch Outside Diameter, with Tang, Bright Finish
Item #: 70547997
Brand: Heli-Coil
Model #: A3585-4GN375
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 1/4-20 |
Overall Insert Length (Decimal Inch) | 0.3750 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Length to Diameter Ratio | 1-1/2D |
Number of Inserts | 1 |
Material | Titanium |
Minimum Outside Diameter (Decimal Inch) | 0.3100 |
Maximum Outside Diameter (Decimal Inch) | 0.3300 |
Finish/Coating | Bright |
Number of Free Coils | 5-3/4 |
Maximum Locking Torque (In/Lb) | 30 |
Minimum Break Away Torque (In/Lb) | 4.50 |
Thread Standard | UNC |
