Brand: Widia / Part #: 2003793

Brand: Widia / Part #: 2003793


Item #: 09790130
Brand: Widia
Model #: 2003793

Product Specifications

Minimum Cutting Diameter (Decimal Inch) 2.5000
Maximum Cutting Diameter (Decimal Inch) 2.5000
Maximum Depth of Cut (Decimal Inch) 0.4460
Arbor Hole Diameter (Decimal Inch) 0.7500
Compatible Insert Size Code XD.T1104..
Maximum Ramping Angle 1.5
Cutter Style VSM
Cutting Direction Right Hand
Insert Holding Method Screw
Lead Angle 90
Rake Negative (Radial); Positive (Axial)
Rake Angle -4.230
Series VSM11
Maximum Body Diameter (Decimal Inch) 2.4290
Overall Height (Decimal Inch) 1.5750
Keyway Width (mm) 8.19
Hub Diameter (Decimal Inch) 1.7500
Maximum RPM 17400.000
Tool Application Milling; Slotting; Ramping
Tool Performance General Purpose
Primary Workpiece Material Universal
Number of Adjustable Pockets 0
ISO Number VSM11D250Z06S075XD11
Coolant Hole Diameter (Decimal Inch) 0.0980
Complete Insert Compatibility XD_T110408PD_R__
Toolholder Material Steel
Manufacturers Catalog Number VSM11D250Z06S075XD11
Coolant Through Yes
Number Of Cutter Inserts 6
Number Of Flutes 6
$1,441.13
