Made in USA - 3/4" Diam, 70° Tooth Angle, 50 TPI, Convex, Form Type Cobalt Left-Hand Diagonal Knurl Wheel - 3/8" Face Width, 1/4" Hole, Circular Pitch, Ferritic Nitrocarburizing Finish, Series KPV - Exact Industrial Supply

Made in USA - 3/4" Diam, 70° Tooth Angle, 50 TPI, Convex, Form Type Cobalt Left-Hand Diagonal Knurl Wheel - 3/8" Face Width, 1/4" Hole, Circular Pitch, Ferritic Nitrocarburizing Finish, Series KPV


Item #: 70100581
Brand: Made in USA
Exact Tooling IR#: 04

Features and Benefits

Left-hand diagonal wheels are designed to produce right-hand diagonal patterns. On a two-wheel knurling tool, left and right diagonal wheels are used together to create a diamond design.
Form wheels produce textured patterns by forming an impression. This process displaces the material and increases the diameter of the workpiece.
Cobalt is harder than high speed steel and provides better wear resistance. It is commonly used on high tensile alloys.
Product Specifications
Knurl Shape Convex
Pattern Left-Hand Diagonal
Form or Cut Type Form
Material Cobalt
Knurl Diameter (Decimal Inch) 0.7500
Knurl Diameter (Inch) 3/4
Face Width (Decimal Inch) 0.3750
Face Width (Inch) 3/8
Hole Diameter (Decimal Inch) 0.2500
Hole Diameter (Inch) 1/4
Pitch System Circular
Pitch (TPI) 50
Knurl Series KPV
Included Tooth Angle 70
Finish/Coating Ferritic Nitrocarburizing
$67.73
