Heli-Coil - Single Insert, M12x1.75 Metric Coarse, 2D, Stainless Steel Screw Locking Insert - 11-1/2 Free Coils, 24mm Overall Length, 14.3 to 15mm Outside Diameter, with Tang, Bright Finish, 304 Material Grade
Item #: 70066022
Brand: Heli-Coil
Model #: A4184-12CN240
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | M12x1.75 |
Overall Insert Length (mm) | 24.00 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 2D |
Length to Diameter Ratio | 2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (mm) | 14.30 |
Maximum Outside Diameter (mm) | 15.00 |
Finish/Coating | Bright |
Number of Free Coils | 11-1/2 |
Maximum Locking Torque (N/m) | 15.00 |
Minimum Break Away Torque (N/m) | 2.2000 |
Thread Standard | Metric Coarse |
Material Grade | 304 |
