Heli-Coil - Single Insert, M12x1.75 Metric Coarse, 1-1/2D, Stainless Steel Screw Locking Insert - 8-1/4 Free Coils, 18mm Overall Length, 14.3 to 15mm Outside Diameter, with Tang, Bright Finish, 304 Material Grade
Item #: 70066014
Brand: Heli-Coil
Model #: A4184-12CN180
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | M12x1.75 |
Overall Insert Length (mm) | 18.00 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Length to Diameter Ratio | 1-1/2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (mm) | 14.30 |
Maximum Outside Diameter (mm) | 15.00 |
Finish/Coating | Bright |
Number of Free Coils | 8-1/4 |
Maximum Locking Torque (N/m) | 15.00 |
Minimum Break Away Torque (N/m) | 2.2000 |
Thread Standard | Metric Coarse |
Material Grade | 304 |
