Heli-Coil - Single Insert, M10x1.5 Metric Coarse, 1-1/2D, Stainless Steel Screw Locking Insert - 8 Free Coils, 15mm Overall Length, 11.95 to 12.5mm Outside Diameter, with Tang, Bright Finish, 304 Material Grade - Exact Industrial Supply

Heli-Coil - Single Insert, M10x1.5 Metric Coarse, 1-1/2D, Stainless Steel Screw Locking Insert - 8 Free Coils, 15mm Overall Length, 11.95 to 12.5mm Outside Diameter, with Tang, Bright Finish, 304 Material Grade


Item #: 70065867
Brand: Heli-Coil
Model #: A4184-10CN150
Exact Tooling IR#: 04

Product Specifications
Thread Size M10x1.50
Overall Insert Length (mm) 15.00
Tang Yes
Tang Tangless
Length to Diameter Ratio 1-1/2D
Length to Diameter Ratio 1-1/2D
Number of Inserts 1
Material Stainless Steel
Minimum Outside Diameter (mm) 11.95
Maximum Outside Diameter (mm) 12.50
Finish/Coating Bright
Number of Free Coils 8
Maximum Locking Torque (N/m) 10.00
Minimum Break Away Torque (N/m) 1.4000
Thread Standard Metric Coarse
Material Grade 304
$2.77
