Heli-Coil - Single Insert, M8x1.25 Metric Coarse, 2D, Stainless Steel Screw Locking Insert - 10-1/4 Free Coils, 16mm Overall Length, 9.8 to 10.35mm Outside Diameter, with Tang, Bright Finish, 304 Material Grade
Item #: 70065727
Brand: Heli-Coil
Model #: A4184-8CN160
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | M8x1.25 |
Overall Insert Length (mm) | 16.00 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 2D |
Length to Diameter Ratio | 2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (mm) | 9.80 |
Maximum Outside Diameter (mm) | 10.35 |
Finish/Coating | Bright |
Number of Free Coils | 10-1/4 |
Maximum Locking Torque (N/m) | 6.00 |
Minimum Break Away Torque (N/m) | 0.8000 |
Thread Standard | Metric Coarse |
Material Grade | 304 |
