![Heli-Coil - Single Insert, M4x0.7 Metric Coarse, 1-1/2D, Stainless Steel Screw Locking Insert - 6-1/8 Free Coils, 6mm Overall Length, 5.05 to 5.6mm Outside Diameter, with Tang, Bright Finish, 304 Material Grade - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/7006531-23_1024x1024.jpg?v=1586459564)
Heli-Coil - Single Insert, M4x0.7 Metric Coarse, 1-1/2D, Stainless Steel Screw Locking Insert - 6-1/8 Free Coils, 6mm Overall Length, 5.05 to 5.6mm Outside Diameter, with Tang, Bright Finish, 304 Material Grade
Item #: 70065313
Brand: Heli-Coil
Model #: A4184-4CN060
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | M4x0.70 |
Overall Insert Length (mm) | 6.00 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Length to Diameter Ratio | 1-1/2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (mm) | 5.05 |
Maximum Outside Diameter (mm) | 5.60 |
Finish/Coating | Bright |
Number of Free Coils | 6-1/8 |
Maximum Locking Torque (N/m) | 0.90 |
Minimum Break Away Torque (N/m) | 0.1600 |
Thread Standard | Metric Coarse |
Material Grade | 304 |
