Heli-Coil - Single Insert, M3x0.5 Metric Coarse, 1D, Stainless Steel Screw Locking Insert - 3-3/4 Free Coils, 3mm Overall Length, 3.8 to 4.35mm Outside Diameter, with Tang, Bright Finish, 304 Material Grade - Exact Industrial Supply

Heli-Coil - Single Insert, M3x0.5 Metric Coarse, 1D, Stainless Steel Screw Locking Insert - 3-3/4 Free Coils, 3mm Overall Length, 3.8 to 4.35mm Outside Diameter, with Tang, Bright Finish, 304 Material Grade


Item #: 70065107
Brand: Heli-Coil
Model #: A4184-3CN030
Exact Tooling IR#: 04

Product Specifications
Thread Size M3x0.50
Overall Insert Length (mm) 3.00
Tang Yes
Tang Tangless
Length to Diameter Ratio 1D
Length to Diameter Ratio 1D
Number of Inserts 1
Material Stainless Steel
Minimum Outside Diameter (mm) 3.80
Maximum Outside Diameter (mm) 4.35
Finish/Coating Bright
Number of Free Coils 3-3/4
Maximum Locking Torque (N/m) 0.44
Minimum Break Away Torque (N/m) 0.1000
Thread Standard Metric Coarse
Material Grade 304
$1.58
