Associated Spring Raymond - 15mm OD, 47.56 N Max Load, 201.9mm Max Ext Len, Stainless Steel Extension Spring - 1.83 Lb/In Rating, 1.61 Lb Init Tension, 76.9mm Free Length
Item #: 69156768
Brand: Associated Spring Raymond
Model #: T42030
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Stainless Steel |
Spring Rate Pounds per Inch (Pounds) | 1.8300 |
Initial Tension (N) | 7.13999987 |
Initial Tension (Lb.) | 1.61000001 |
Free Length (mm) | 76.90 |
Free Length (Decimal Inch) | 3.0276 |
Outside Diameter (mm) | 15 |
Outside Diameter (Decimal Inch) | 0.5906 |
Maximum Work Load (N) | 47.56000137 |
Maximum Extended Length (mm) | 201.90 |
Maximum Extended Length (Decimal Inch) | 7.9488 |
