Associated Spring Raymond - 6mm OD, 9.5 N Max Load, 39.7mm Max Ext Len, Music Wire Extension Spring - 2.1 Lb/In Rating, 0.25 Lb Init Tension, 17.2mm Free Length
Item #: 69154375
Brand: Associated Spring Raymond
Model #: T31010
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Music Wire |
Spring Rate Pounds per Inch (Pounds) | 2.1000 |
Initial Tension (N) | 1.09000003 |
Initial Tension (Lb.) | 1/4 |
Free Length (mm) | 17.20 |
Free Length (Decimal Inch) | 0.6772 |
Outside Diameter (mm) | 6 |
Outside Diameter (Decimal Inch) | 0.2362 |
Maximum Work Load (N) | 9-1/2 |
Maximum Extended Length (mm) | 39.70 |
Maximum Extended Length (Decimal Inch) | 1.5630 |
