Associated Spring Raymond - 8.5mm OD, 52.31 N Max Load, 515mm Max Ext Len, Spring - 1.14 Lb/In Rating, 1.73 Lb Init Tension, 290mm Free Length
Item #: 69131357
Brand: Associated Spring Raymond
Model #: T41860
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Spring Rate Pounds per Inch (Pounds) | 1.1400 |
Initial Tension (N) | 7.67999983 |
Initial Tension (Lb.) | 1.73000002 |
Free Length (mm) | 290 |
Free Length (Decimal Inch) | 11.4173 |
Outside Diameter (mm) | 8-1/2 |
Outside Diameter (Decimal Inch) | 0.3346 |
Maximum Work Load (N) | 52.31000137 |
Maximum Extended Length (mm) | 515 |
Maximum Extended Length (Decimal Inch) | 20.2756 |
