Associated Spring Raymond - 31.75mm OD, 115.03 N Max Load, 394.21mm Max Ext Len, Spring - 2.3 Lb/In Rating, 2.33 Lb Init Tension, 139.7mm Free Length
Item #: 69128262
Brand: Associated Spring Raymond
Model #: E12500955500M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Spring Rate Pounds per Inch (Pounds) | 2.3000 |
Initial Tension (N) | 10.35999966 |
Initial Tension (Lb.) | 2.32999992 |
Free Length (mm) | 139.70 |
Free Length (Decimal Inch) | 5-1/2 |
Outside Diameter (mm) | 31-3/4 |
Outside Diameter (Decimal Inch) | 1-1/4 |
Maximum Work Load (N) | 115.02999878 |
Maximum Extended Length (mm) | 394.21 |
Maximum Extended Length (Decimal Inch) | 15.5200 |
