Associated Spring Raymond - 25.4mm OD, 311.16 N Max Load, 123.19mm Max Ext Len, Spring - 47.23 Lb/In Rating, 6.3 Lb Init Tension, 88.9mm Free Length
Item #: 69127264
Brand: Associated Spring Raymond
Model #: E10001353500S
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Spring Rate Pounds per Inch (Pounds) | 47.2300 |
Initial Tension (N) | 28.01000023 |
Initial Tension (Lb.) | 6.30000019 |
Free Length (mm) | 88.90 |
Free Length (Decimal Inch) | 3-1/2 |
Outside Diameter (mm) | 25.40 |
Outside Diameter (Decimal Inch) | 1 |
Maximum Work Load (N) | 311.16000366 |
Maximum Extended Length (mm) | 123.19 |
Maximum Extended Length (Decimal Inch) | 4.8500 |
