Associated Spring Raymond - 25.4mm OD, 187.94 N Max Load, 215.65mm Max Ext Len, Spring - 9.6 Lb/In Rating, 3.8 Lb Init Tension, 114.3mm Free Length
Item #: 69126589
Brand: Associated Spring Raymond
Model #: E10001054500M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Spring Rate Pounds per Inch (Pounds) | 9.6000 |
| Initial Tension (N) | 16.89999962 |
| Initial Tension (Lb.) | 3.79999995 |
| Free Length (mm) | 114.30 |
| Free Length (Decimal Inch) | 4-1/2 |
| Outside Diameter (mm) | 25.40 |
| Outside Diameter (Decimal Inch) | 1 |
| Maximum Work Load (N) | 187.94000244 |
| Maximum Extended Length (mm) | 215.65 |
| Maximum Extended Length (Decimal Inch) | 8.4900 |
