Associated Spring Raymond - 25.4mm OD, 35.94 N Max Load, 225.81mm Max Ext Len, Spring - 1.25 Lb/In Rating, 0.75 Lb Init Tension, 76.2mm Free Length
Item #: 69126019
Brand: Associated Spring Raymond
Model #: E10000633000S
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Spring Rate Pounds per Inch (Pounds) | 1.2500 |
Initial Tension (N) | 3.32999992 |
Initial Tension (Lb.) | 3/4 |
Free Length (mm) | 76.20 |
Free Length (Decimal Inch) | 3 |
Outside Diameter (mm) | 25.40 |
Outside Diameter (Decimal Inch) | 1 |
Maximum Work Load (N) | 35.93999863 |
Maximum Extended Length (mm) | 225.81 |
Maximum Extended Length (Decimal Inch) | 8.8900 |
