Associated Spring Raymond - 19.05mm OD, 63.96 N Max Load, 165.1mm Max Ext Len, Spring - 3.75 Lb/In Rating, 1.29 Lb Init Tension, 76.2mm Free Length
Item #: 69124303
Brand: Associated Spring Raymond
Model #: E07500693000S
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Spring Rate Pounds per Inch (Pounds) | 3.7500 |
Initial Tension (N) | 5.73999977 |
Initial Tension (Lb.) | 1.28999996 |
Free Length (mm) | 76.20 |
Free Length (Decimal Inch) | 3 |
Outside Diameter (mm) | 19.05 |
Outside Diameter (Decimal Inch) | 3/4 |
Maximum Work Load (N) | 63.95999908 |
Maximum Extended Length (mm) | 165.10 |
Maximum Extended Length (Decimal Inch) | 6-1/2 |
