Associated Spring Raymond - 12.7mm OD, 29.06 N Max Load, 187.71mm Max Ext Len, Stainless Steel Extension Spring - 1.9 Lb/In Rating, 1 Lb Init Tension, 114.3mm Free Length
Item #: 69122562
Brand: Associated Spring Raymond
Model #: E05000554500X
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Stainless Steel |
Spring Rate Pounds per Inch (Pounds) | 1.9000 |
Initial Tension (N) | 0.22499999 |
Initial Tension (Lb.) | 1 |
Free Length (mm) | 114.30 |
Free Length (Decimal Inch) | 4-1/2 |
Outside Diameter (mm) | 12.70 |
Outside Diameter (Decimal Inch) | 1/2 |
Maximum Work Load (N) | 29.05999947 |
Maximum Extended Length (mm) | 187.71 |
Maximum Extended Length (Decimal Inch) | 7.3900 |
