Associated Spring Raymond - 12.7mm OD, 43.37 N Max Load, 219.46mm Max Ext Len, Music Wire Extension Spring - 1.7 Lb/In Rating, 0.88 Lb Init Tension, 88.9mm Free Length
Item #: 69122307
Brand: Associated Spring Raymond
Model #: E05000493500M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Music Wire |
Spring Rate Pounds per Inch (Pounds) | 1.7000 |
Initial Tension (N) | 3.91000009 |
Initial Tension (Lb.) | 0.88000000 |
Free Length (mm) | 88.90 |
Free Length (Decimal Inch) | 3-1/2 |
Outside Diameter (mm) | 12.70 |
Outside Diameter (Decimal Inch) | 1/2 |
Maximum Work Load (N) | 43.36999893 |
Maximum Extended Length (mm) | 219.46 |
Maximum Extended Length (Decimal Inch) | 8.6400 |
