Associated Spring Raymond - 12.7mm OD, 21.49 N Max Load, 108.97mm Max Ext Len, Stainless Steel Extension Spring - 1.67 Lb/In Rating, 0.42 Lb Init Tension, 44.45mm Free Length
Item #: 69121762
Brand: Associated Spring Raymond
Model #: E05000411750S
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Stainless Steel |
Spring Rate Pounds per Inch (Pounds) | 1.6700 |
Initial Tension (N) | 1.85000002 |
Initial Tension (Lb.) | 0.41999999 |
Free Length (mm) | 44.45 |
Free Length (Decimal Inch) | 1-3/4 |
Outside Diameter (mm) | 12.70 |
Outside Diameter (Decimal Inch) | 1/2 |
Maximum Work Load (N) | 21.48999977 |
Maximum Extended Length (mm) | 108.97 |
Maximum Extended Length (Decimal Inch) | 4.2900 |
