Associated Spring Raymond - 10.67mm OD, 10.68 N Max Load, 54.36mm Max Ext Len, Stainless Steel Extension Spring - 2.6 Lb/In Rating, 0.42 Lb Init Tension, 34.8mm Free Length
Item #: 69120848
Brand: Associated Spring Raymond
Model #: E04200371370X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Extension |
| Material | Stainless Steel |
| Spring Rate Pounds per Inch (Pounds) | 2.6000 |
| Initial Tension (N) | 0.09400000 |
| Initial Tension (Lb.) | 0.41999999 |
| Free Length (mm) | 34.80 |
| Free Length (Decimal Inch) | 1.3700 |
| Outside Diameter (mm) | 10.67 |
| Outside Diameter (Decimal Inch) | 0.4200 |
| Maximum Work Load (N) | 10.68000031 |
| Maximum Extended Length (mm) | 54.36 |
| Maximum Extended Length (Decimal Inch) | 2.1400 |
