Associated Spring Raymond - 9.14mm OD, 78.29 N Max Load, 241.3mm Max Ext Len, Music Wire Extension Spring - 4.7 Lb/In Rating, 1.6 Lb Init Tension, 152.4mm Free Length
Item #: 69120467
Brand: Associated Spring Raymond
Model #: E03600556000M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Extension |
| Material | Music Wire |
| Spring Rate Pounds per Inch (Pounds) | 4.7000 |
| Initial Tension (N) | 7.11999989 |
| Initial Tension (Lb.) | 1.60000002 |
| Free Length (mm) | 152.40 |
| Free Length (Decimal Inch) | 6 |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Maximum Work Load (N) | 78.29000092 |
| Maximum Extended Length (mm) | 241.30 |
| Maximum Extended Length (Decimal Inch) | 9-1/2 |
