![Associated Spring Raymond - 9.14mm OD, 65.22 N Max Load, 47.5mm Max Ext Len, Stainless Steel Extension Spring - 26.74 Lb/In Rating, 1.33 Lb Init Tension, 34.8mm Free Length - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/6909855-21_29bf4756-1cc8-4a3e-80e3-88b04ce3a81a_1024x1024.jpg?v=1586654557)
Associated Spring Raymond - 9.14mm OD, 65.22 N Max Load, 47.5mm Max Ext Len, Stainless Steel Extension Spring - 26.74 Lb/In Rating, 1.33 Lb Init Tension, 34.8mm Free Length
Item #: 69120269
Brand: Associated Spring Raymond
Model #: E03600551370S
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Stainless Steel |
Spring Rate Pounds per Inch (Pounds) | 26.7400 |
Initial Tension (N) | 5.92999983 |
Initial Tension (Lb.) | 1.33000004 |
Free Length (mm) | 34.80 |
Free Length (Decimal Inch) | 1.3700 |
Outside Diameter (mm) | 9.14 |
Outside Diameter (Decimal Inch) | 0.3600 |
Maximum Work Load (N) | 65.22000122 |
Maximum Extended Length (mm) | 47-1/2 |
Maximum Extended Length (Decimal Inch) | 1.8700 |
