Associated Spring Raymond - 9.14mm OD, 37.79 N Max Load, 224.28mm Max Ext Len, Stainless Steel Extension Spring - 1.83 Lb/In Rating, 0.75 Lb Init Tension, 114.3mm Free Length
Item #: 69119881
Brand: Associated Spring Raymond
Model #: E03600454500S
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Stainless Steel |
Spring Rate Pounds per Inch (Pounds) | 1.8300 |
Initial Tension (N) | 3.32999992 |
Initial Tension (Lb.) | 3/4 |
Free Length (mm) | 114.30 |
Free Length (Decimal Inch) | 4-1/2 |
Outside Diameter (mm) | 9.14 |
Outside Diameter (Decimal Inch) | 0.3600 |
Maximum Work Load (N) | 37.79000092 |
Maximum Extended Length (mm) | 224.28 |
Maximum Extended Length (Decimal Inch) | 8.8300 |
