Associated Spring Raymond - 9.14mm OD, 35.14 N Max Load, 46.99mm Max Ext Len, Music Wire Extension Spring - 9.9 Lb/In Rating, 0.7 Lb Init Tension, 28.45mm Free Length
Item #: 69119360
Brand: Associated Spring Raymond
Model #: E03600411120M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Music Wire |
Spring Rate Pounds per Inch (Pounds) | 9.9000 |
Initial Tension (N) | 3.10999990 |
Initial Tension (Lb.) | 0.69999999 |
Free Length (mm) | 28.45 |
Free Length (Decimal Inch) | 1.1200 |
Outside Diameter (mm) | 9.14 |
Outside Diameter (Decimal Inch) | 0.3600 |
Maximum Work Load (N) | 35.13999939 |
Maximum Extended Length (mm) | 46.99 |
Maximum Extended Length (Decimal Inch) | 1.8500 |
