![Associated Spring Raymond - 9.14mm OD, 14.86 N Max Load, 115.06mm Max Ext Len, Stainless Steel Extension Spring - 1.6 Lb/In Rating, 0.52 Lb Init Tension, 69.85mm Free Length - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/6909855-21_a049e354-07ee-4545-b6a1-e3eafa6d76ba_1024x1024.jpg?v=1586245586)
Associated Spring Raymond - 9.14mm OD, 14.86 N Max Load, 115.06mm Max Ext Len, Stainless Steel Extension Spring - 1.6 Lb/In Rating, 0.52 Lb Init Tension, 69.85mm Free Length
Item #: 69119329
Brand: Associated Spring Raymond
Model #: E03600392750X
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Stainless Steel |
Spring Rate Pounds per Inch (Pounds) | 1.6000 |
Initial Tension (N) | 0.11700000 |
Initial Tension (Lb.) | 0.51999998 |
Free Length (mm) | 69.85 |
Free Length (Decimal Inch) | 2-3/4 |
Outside Diameter (mm) | 9.14 |
Outside Diameter (Decimal Inch) | 0.3600 |
Maximum Work Load (N) | 14.85999966 |
Maximum Extended Length (mm) | 115.06 |
Maximum Extended Length (Decimal Inch) | 4.5300 |
