Associated Spring Raymond - 9.14mm OD, 26.24 N Max Load, 291.85mm Max Ext Len, Music Wire Extension Spring - 0.8 Lb/In Rating, 0.5 Lb Init Tension, 114.3mm Free Length
Item #: 69119113
Brand: Associated Spring Raymond
Model #: E03600374500M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Extension |
| Material | Music Wire |
| Spring Rate Pounds per Inch (Pounds) | 0.8000 |
| Initial Tension (N) | 2.22000003 |
| Initial Tension (Lb.) | 1/2 |
| Free Length (mm) | 114.30 |
| Free Length (Decimal Inch) | 4-1/2 |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Maximum Work Load (N) | 26.23999977 |
| Maximum Extended Length (mm) | 291.85 |
| Maximum Extended Length (Decimal Inch) | 11.4900 |
