Associated Spring Raymond - 9.14mm OD, 17.71 N Max Load, 191.52mm Max Ext Len, Stainless Steel Extension Spring - 0.75 Lb/In Rating, 0.36 Lb Init Tension, 69.85mm Free Length
Item #: 69118768
Brand: Associated Spring Raymond
Model #: E03600342750S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Extension |
| Material | Stainless Steel |
| Spring Rate Pounds per Inch (Pounds) | 0.7500 |
| Initial Tension (N) | 1.59000003 |
| Initial Tension (Lb.) | 0.36000001 |
| Free Length (mm) | 69.85 |
| Free Length (Decimal Inch) | 2-3/4 |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Maximum Work Load (N) | 17.70999908 |
| Maximum Extended Length (mm) | 191.52 |
| Maximum Extended Length (Decimal Inch) | 7.5400 |
