![Associated Spring Raymond - 9.14mm OD, 13.67 N Max Load, 222.25mm Max Ext Len, Stainless Steel Extension Spring - 0.5 Lb/In Rating, 0.28 Lb Init Tension, 69.85mm Free Length - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/6909855-21_177a57a7-6a92-4aed-b2d3-2745845475d6_1024x1024.jpg?v=1586245523)
Associated Spring Raymond - 9.14mm OD, 13.67 N Max Load, 222.25mm Max Ext Len, Stainless Steel Extension Spring - 0.5 Lb/In Rating, 0.28 Lb Init Tension, 69.85mm Free Length
Item #: 69118537
Brand: Associated Spring Raymond
Model #: E03600312750S
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Stainless Steel |
Spring Rate Pounds per Inch (Pounds) | 0.5000 |
Initial Tension (N) | 1.22000003 |
Initial Tension (Lb.) | 0.28000000 |
Free Length (mm) | 69.85 |
Free Length (Decimal Inch) | 2-3/4 |
Outside Diameter (mm) | 9.14 |
Outside Diameter (Decimal Inch) | 0.3600 |
Maximum Work Load (N) | 13.67000008 |
Maximum Extended Length (mm) | 222-1/4 |
Maximum Extended Length (Decimal Inch) | 8-3/4 |
