Associated Spring Raymond - 9.14mm OD, 37.79 N Max Load, 22.1mm Max Ext Len, Stainless Steel Extension Spring - 63.72 Lb/In Rating, 0.75 Lb Init Tension, 19.05mm Free Length
Item #: 69117265
Brand: Associated Spring Raymond
Model #: E03600450750S
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Stainless Steel |
Spring Rate Pounds per Inch (Pounds) | 63.7200 |
Initial Tension (N) | 3.32999992 |
Initial Tension (Lb.) | 3/4 |
Free Length (mm) | 19.05 |
Free Length (Decimal Inch) | 3/4 |
Outside Diameter (mm) | 9.14 |
Outside Diameter (Decimal Inch) | 0.3600 |
Maximum Work Load (N) | 37.79000092 |
Maximum Extended Length (mm) | 22.10 |
Maximum Extended Length (Decimal Inch) | 0.8700 |
